Stainless Steel 310 Stud Bolts, SS 310S Studs, 310 Stainless Steel Double End Stud Bolt

SS 310S Double End Stud Bolts, 310 Stainless Steel Stud Bolts Manufacturer, 310 SS Threaded Rod, SS 310S Stud Bolts Manufacturer In India.

Aashish Metal & Alloys is a recognized trader of Stainless Steel 310 / 310S Stud Bolts, which are a molybdenum containing and carbon austenitic alloy.

Meanwhile, it’s far used for chemical processing, oil refineries, paper mills, meals processing, etc. In addition, it’s far definitely a molybdenum bearing, low carbon content material “L” grade austenitic stainless-steel. Also, Stainless Steel UNS S31000 Stud Bolts possesses the identical excessive energy and corrosion resistance. It is supposed to offer stepped forward corrosion resistance relative in especially corrosive system environments, in particular the ones containing chlorides or different halides. They are extra proof against trendy corrosion and pitting/crevice corrosion than the traditional chromium-nickel austenitic steels. It is a widespread for an austenitic style of stainless-steel which suggests that this metal is low-carbon subtype of marine grade stainless-steel.

SS 310 Studs, DIN 1.4841 Industrial Stud Bolt, UNS S31008 Stud Bolts, SS 310S Full Threaded Stud Bolt, 310S Half Thread Stud Bolts, DIN 1.4845 Tie Rods, 310 Tap End Stud Bolts, UNS S31000 Single End Stud Bolt Supplier in Mumbai, India.

In addition, it’s far extra proof against trendy corrosion and pitting than traditional nickel chromium stainless steels. Stainless Steel WNR. 1.4841 Stud Bolts offers an additional stage of resistance to atmospheric corrosion, to plenty of natural and inorganic chemical substances and to meals and beverages. It is ideally fitted for packages requiring corrosion resistance. It is 2nd in ordinary quantity manufacturing to among the austenitic alloys. It usually incorporates molybdenum to face up to the corrosive results of NaCl or salt in seawater. It is appropriate for welding as it has carbon content material decrease collection alloys to keep away from carbide precipitation in welding packages.

Molybdenum addition in Stainless Steel UNS S31008 Stud Bolts will increase trendy corrosion resistance and improves resistance to pitting from chloride ion solutions. It resists oxidation and is likewise used at temperatures as much as 1040 levels Celsius intermittently. It is an austenitic alloy evolved to be used in excessive temperature corrosion resistant packages. It gives brilliant resistance to oxidation beneath mildly cyclic situations thru 2000 Degree F. It is one of the maximum broadly used warmth resistant stainless-steel provided into several enterprise sectors. They are available at industry leading prices and are reliable, where we source the best quality material for manufacturing our products.

Stainless Steel 310/310S stud bolts Specifications

Specifications	ASTM A193 / ASME SA193
Standard	IS, BS, ASTM, ASME
Length	3mm to 200mm
Nuts Size	M02 to M33, Custom Sizes
Dimension Standard	DIN 933, ISO 4017, DIN 931, ISO 4014, DIN 982, DIN 985, DIN 912, ISO 7380, DIN 7991, DIN 125, ISO 7379, DIN 127, DIN 1481, DIN 975, DIN 6923, DIN 934, DIN 7984
External Coating	Teflon Coating, Oxidized, Zinc Plating, Chrome Plating, Mirror Buffed, Hot Dipped Galvanizing, Epoxy Coating, Electro Polished, Passivation
Testing and Documents	Mill Test Certificates, EN 10204 3.1, Chemical Reports, Mechanical Reports, Destructive Test Report, Non Destructive Test Reports, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, NABL Approved Lab Reports
Packing	Packed in Wooden Boxes, Bubble wraps, Steel Strips Bundled, or as per Customers Requests

Stainless Steel 310/310S stud bolts Equivalent Grades

AISI Grade Equivalent	JIS Equivalent	Stainless Steel Notation	EN/DIN Numerical Equivalent	UNS designation	EN/DIN Symbolical Equivalent
AISI 310	SUS 310	SS 310	1.4841	UNS S31000	X15CrNi25-20
AISI 310S	SUS 310S	SS 310S	1.4845	UNS S31008	X8CrNi25-21

Stainless Steel 310/310S stud bolts Quality and Test reports

310/310S stud bolts Surface Coating

Xylon Coated Washers
Hot Dipped Galvanizing Coated Washers
Teflon Coated Washers
PTFE Coated Washers
Zinc Coated Washers
Phosphate Coated Washers
Cadmium Coated Washers

Stainless Steel 310/310S stud bolts Standard

ASTM	ASTM A193 Stud Bolt	ASTM A307 Stud Bolt	ASTM A320 Stud Bolt
	ASTM A325 Stud Bolt	ASTM A354 Stud Bolt	ASTM A449 Stud Bolt
	ASTM A490 Stud Bolt	ASTM F568 Stud Bolt	ASTM F593 Stud Bolt
	ASTM F1554 Stud Bolt	ASTM A325M Stud Bolt	ASTM A490M Stud Bolt
IS	IS 1363 Stud Bolt	IS 1364 Stud Bolt	IS 2585 Stud Bolt
	IS 3138 Stud Bolt	IS 3640 Stud Bolt	IS 10238 Stud Bolt
	IS 3757 Stud Bolt	IS 6639 Stud Bolt
DIN	DIN 931 Stud Bolt	DIN 933 Stud Bolt	DIN 938 Stud Bolt
	DIN 939 Stud Bolt	DIN 960 Stud Bolt	DIN 961 Stud Bolt
	DIN 975 Stud Bolt	DIN 2510 Stud Bolt	DIN 7990 Stud Bolt
	DIN 610 Stud Bolt	DIN 6914 Stud Bolt	DIN 6915 Stud Bolt
BS	BS 1083 Stud Bolt	BS 1768 Stud Bolt	BS 1769 Stud Bolt
ANSI / ASME	ASME B18.2.1 Stud Bolt	ASME B18.31.3 Stud Bolt	ASME B16.5 Stud Bolt
ANSI / ASME	ANSI B18.2.1 Stud Bolt	ANSI / ASME B18.1.1 Stud Bolt
ISO	ISO 7412 Stud Bolt

We Supplied a Comprehensive Range Of 310/310S Stainless Steel Stud Bolts

Buy 310 Stainless Steel Stud Bolts only From PED Approved Manufacturer

Stainless Steel 310/310S Stud Bolts

Stainless Steel 310/310S Double Ended Studs

Stainless Steel 310/310S Threaded Rod

Stainless Steel 310/310S Tie Rods

Stainless Steel 310/310S stud bolts Size

Class 150 Flanges ASME B16.5 (Stud bolt sizes)						Length of Stud Bolts
NPS	Outside Diameter of Flange	The diameter of Bolt Circle	The diameter of Bolt Holes	Number of Bolts	Diameter of Bolts	Raised Face 0.06 in	Ring Joint
1/2	3 1/2	2 3/8	5/8	4	1/2	2 1/4	–
3/4	3 7/8	2 3/4	5/8	4	1/2	2 1/2	–
1	4 1/4	3 1/8	5/8	4	1/2	2 1/2	3
1 1/4	4 5/8	3 1/2	5/8	4	1/2	2 3/4	3 1/4
1 1/2	5	3 7/8	5/8	4	1/2	2 3/4	3 1/4
2	6	4 3/4	3/4	4	5/8	3 1/4	3 3/4
2 1/2	7	5 1/2	3/4	4	5/8	3 1/2	4
3	7 1/2	6	3/4	4	5/8	3 1/2	4
3 1/2	8 1/2	7	3/4	8	5/8	3 1/2	4
4	9	7 1/2	3/4	8	5/8	3 1/2	4
5	10	8 1/2	7/8	8	3/4	3 3/4	4 1/4
6	11	9 1/2	7/8	8	3/4	4	4 1/2
8	13 1/2	11 3/4	7/8	8	3/4	4 1/4	4 3/4
10	16	14 3/4	1	12	7/8	4 1/2	5
12	19	17	1	12	7/8	4 3/4	5 1/4
14	21	18 3/4	1 1/8	12	1	5 1/4	5 3/4
16	23 1/2	21 1/4	1 1/8	16	1	5 1/4	5 3/4
18	25	22 3/4	1 1/4	16	1 1/8	5 3/4	6 1/4
20	27 1/2	25	1 1/4	20	1 1/8	6 1/4	6 3/4
24	32	29 1/2	1 1/4	20	1 1/4	6 3/4	7 1/4
Class 300 Flanges ASME B16.5						Length of Stud Bolts
NPS	Outside Diameter of Flange	The diameter of Bolt Circle	The diameter of Bolt Holes	Number of Bolts	Diameter of Bolts	Raised Face 0.06 in	Ring Joint
1/2	3 3/4	2 5/8	5/8	4	1/2	2 1/2	3
3/4	4 5/8	3 1/4	3/4	4	5/8	3	3 1/2
1	4 7/8	3 1/2	3/4	4	5/8	3	3 1/2
1 1/4	5 1/4	3 7/8	3/4	4	5/8	3 1/4	3 3/4
1 1/2	6 1/8	4 1/2	7/8	4	3/4	3 1/2	4
2	6 1/2	5	3/4	8	5/8	3 1/2	4
2 1/2	7 1/2	5 7/8	7/8	8	3/4	4	4 1/2
3	8 1/4	6 5/8	7/8	8	3/4	4 1/4	4 3/4
3 1/2	9	7 1/4	7/8	8	3/4	4 1/4	5
4	10	7 7/8	7/8	8	3/4	4 1/2	5
5	11	9 1/4	7/8	8	3/4	4 3/4	5 1/4
6	12 1/2	10 5/8	7/8	12	3/4	4 3/4	5 1/2
8	15	13	1	12	7/8	5 1/2	6
10	17 1/2	15 1/4	1 1/8	16	1	6 1/4	6 3/4
12	20 1/2	17 3/4	1 1/4	16	1 1/8	6 3/4	7 1/4
14	23	20 1/4	1 1/4	20	1 1/8	7	7 1/2
16	25 1/2	22 1/2	1 3/8	20	1 1/4	7 1/2	8
18	28	24 3/4	1 3/8	24	1 1/4	7 3/4	8 1/4
20	30 1/2	27	1 3/8	24	1 1/4	8	8 3/4
24	36	32	1 5/8	24	1 1/2	9	10

310/310S SS stud bolts Weight Chart

Weight Imperial
STUD BOLT LENGTH (in inches)	1/2	5/8	3/4	7/8	1	1 1/8	1 1/4	1.3/8	1 1/2	1.5/8	1.3/4	1 7/8
2.1/2	10.8
2.3/4	11.6	19.8
3.1/4	12.4	21	32.4
3.1/2	13.2	22.2	34.3	50
4	14	23.4	36.2	52.6	71.8
4.1/2	14.8	24.6	38.1	55.2	75.2	102
4.3/4	15.6	25.8	40	57.8	78.6	106	137
5	16.4	27	41.9	60.4	82	111	142	179
5.1/2	17.2	28.2	43.8	63	85.4	115	147	186	234
6	18	29.4	45.7	65.6	88.8	119	153	193	242	289
6.1/4	18.8	30.6	47.6	68.2	92.2	123	158	200	250	298	263
6.1/2	19.6	32.3	49.5	70.8	95.6	128	164	206	258	308	374	437
7	20.4	33.5	50.8	73.4	99	132	169	213	266	317	385	449
7.1/2	21.2	34.8	52.7	75.5	103	136	174	220	275	326	396	462
8	22	36.1	54.5	78	106	141	180	226	283	336	407	475
8.1/4		37.3	56.3	80.5	108	145	185	233	291	345	418	488
8.3/4		38.6	58.1	83.1	112	149	191	240	299	354	429	500
9		39.8	60	85.6	115	153	196	246	307	364	440	513
9.1/2		41.1	61.8	88.2	118	158	201	253	316	373	451	526
10			63.7	90.7	122	162	206	260	324	382	463	538
10/1.4				93.3	125	166	212	267	332	391	474	551
1.0.1/2					128	171	217	273	340	401	485	564
11					132	175	223	279	345	410	496	576
11.1/2					135	179	228	285	350	419	507	589
12					138	184	233	292	358	429	518	602
Weight Of Metric Studs Bolt
STUD BOLT LENGTH (in mm)	M10	M12	M14	M16	M18	M20	M22	M24	M27	M30	M33	M36	M39
60	5,6	8,1	12	15,6
70	6,1	8,9	13	16,9	23,7
80	6,6	9,6	14	18,2	25,4	32,5
90	7,1	10,3	15	19,6	27,1	34,5	45,5
100	7,6	11	16	21	28,8	36,7	47,2	54,2
110	8,1	11,7	17	22,2	30,4	38,7	48,3	58,2	80
120	8,6	12,4	18	23,6	32,1	40,7	50,9	60,2	84,7	107
130	9,1	13,2	19	24,9	33,7	42,8	53,4	63,2	88,6	111	141
140	9,6	14,2	20	26,2	35,4	44,9	55,9	66,2	92,4	116	147	185
150	10,1	14,9	20,8	27,5	36,9	46,9	58,5	69,2	96,3	121	153	192	237
160	10,6	15,6	21,8	29,1	38,6	49	61	72,2	100,1	126	159	199	245
170		16,4	22,8	30,4	40,2	51,1	63,5	75,2	104	130	165	206	253
180			23,8	31,8	41,9	52,3	66,1	78,1	108	135	171	213	261
190				33,1	43,5	54,4	68,4	81,1	112	140	176	219	269
200				34,5	45,2	56,2	71	84	116	144	182	226	278
210				35,8	46,8	58,5	73,5	88,4	120	149	188	233	286
220				37,1	48,4	60,6	76,1	91,4	124	154	194	240	294
230				38,5	50,1	62,6	78,6	94,4	127	159	201	247	302
240				39,8	51,7	64,7	81,2	97,4	130,9	164	208	253	310
250				41,1	53,4	66,8	83,7	100,4	134,8	172	214	260	319
260					55	68,8	86,3	103,4	138,6	177	220	267	327
270					56,6	70,9	88,8	106,4	142,5	182	224	274	335
280					58,3	73	91,4	109,4	146,3	187	230	281	343
290						75	93,9	112,4	150,1	192	236	291	360
300						77,1	96,5	115,4	154	196	241	298	368
320							101,6	121,3	161,7	206	253	312	380
340								127,3	169,4	215	265	326	395
360								133,3	177,1	224	276	340	411
380									184,8	234	288	353	428
400									192,5	243	299	367	444
420										252	311	381	460
440										262	322	394	477
460										271	334	408	493
480										281	345	422	509
500										290	357	436	526

We Keep Bulk Stock Of 310, 310S Stainless Steel stud bolts, Threaded Rod At Our Stockyard, Contact Us For Free Sample & Stock List.

Chemical Composition

Grade	C	MN	Si	P	S	Cr	Mo	Ni	Fe
SS 310	0.015 max	2.0 Max	0.15 max	0.020 max	0.015 max	24.00 – 26.00	0.1 Max	19– 21	54.7 min
SS 310S	0.08 max	2.0 Max	1.00 max	0.045 max	0.030 Max	24.00 – 26.00	0.75 max	19– 21	53.095 Min

Mechanical Properties

Grade	Tensile Strength (Mpa) Min	Yield Strenght 0.2% Proof (MPa) Min	Elognation (%in 50mm) min	Melting Point
Grade	Tensile Strength (Mpa) Min	Yield Strenght 0.2% Proof (MPa) Min	Elognation (%in 50mm) min
310	Psi – 75000 , MPa – 515	Psi – 30000 , MPa – 205	40 %	1402 °C (2555 °F)
310S	Psi – 75000 , MPa – 515	Psi – 30000 , MPa – 205	40 %	1402 °C (2555 °F)

For Stainless Steel 310/310S stud bolts price list

Request the latest Stainless Steel 310/310S Stud Bolts List. Please click on the request a quote button or click here to request the updated price list and ready stock information along with your requirement. Aashish Metal & Alloys maintains a stock of all standard items and can export them at best price for 310/310S Stainless Steel Stud Bolts.

We supply of variety SS 310/310S stud bolts

Aashish Metal & Alloys is a Highly Acclaimed Manufacturer & suppliers of Stainless Steel 310/310S Stud Bolts offering more than 3000 varieties in all types of 310 Stainless Steel in all sizes, with more then 52 countries worldwide.

Stainless Steel 310 Threaded Rod	Stainless Steel 310S Tie Rod
ASTM A193 SS 310S Studs	310 Stainless Steel Double Ended Stud
Stainless Steel ASTM A193 310S Stud	Stainless Steel 1.4841 Threaded Studs
SS 310 Half Thread Stud Bolt Stockist	SS UNS S31000 Continuous Thread Stud Bolt Supplier
ASME SA193 310 SS Partial Threaded Stud Bolt	310S Stainless Steel Reduced Shank Stud Bolt
310 SS Stud Bolts Exporter	S31008 Stainless Steel Single Ended Stud Bolt
1.4845 Stud Bolt Specification	AISI 310 Stainless Steel Metric Thread Stud Bolt
Grade 310S SS Stud Bolts Manufacturer	Stainless Steel 310 Stud Bolts Distributor
UNS S31000 Stud Bolts	Stainless Steel 310S Industrial Stud Bolt Price
Stainless Steel UNS S31008 Studs	DIN 1.4841 Stud Bolt
310S SS Stud Bolt Dealer	1.4845 Threaded Rods
310S Stainless Steel Tie Rod	ASME SA193 310 Stainless Steel Flush Head Studs
Stainless Steel SUS 310S Threaded Rods	Stainless Steel S31008 Flush Head Stud

Application Of SS 310/310S stud bolts

We Serve

Application Industry

Automotive and aerospace industry, Chemical industry, Heat exchanger, Food processing equipment, Architectural trim and molding, Kitchen benches, sinks, equipmentrtc

For More Information About Stainless Steel 310/310S Stud Bolts please call +91-22-66362223 / 66394926 or send an email to export@aashishmetal.com
