Stainless Steel 904L Round Bars
SS 904L Square Bar, ASTM A276 SS 904L Rods, 904L Stainless Steel Round Bar Manufacturer in India, Stainless Steel 904L Flat Bar, Stainless Steel 904L Round Bar, SS 904L Bars Stockist In India.
Aashish Metal & Alloys is a prominent manufacturer and trader of SS 904L Round Bars, which also can be utilized in clean and in a variety of different development waters.
Meanwhile, sulphurous environments are mordant to those alloys and may be cold rolled to more than a few tempers. Stainless Steel UNS N08904 Triangular Bars is at instances joined with the aid of using the use of threaded connections, wherein tapered threads are being reduce into the stop of the tubing section, sealant is implemented within the shape of thread sealing compound or thread seal tape, and it’s far after that threaded into an equal threaded becoming with the aid of using the use of pipe wrenches. Taking the gain of those traits, it’s far utilized in warmth exchangers, seawater desalination plant, superimpose materials for marine formations, and related applications.
- Stainless Steel 904L Round Bars Specifications
- Stainless Steel 904L Round Bars Equivalent Grades
- Stainless Steel 904L Round Bars Quality and Test reports
- SS 904L Round Bars Surface Finish
- Related Types Of Stainless Steel 904L Round Bars
- Dimensions Of Hot Rolled Stainless Steel 904L Round Bar
- Stainless Steel 904L Round Bar Size Chart
- Standard Sizes ASTM A276 Stainless Steel 904L Hex Bar
- Stainless Steel 904L Flat Bar Size
- Size chart of SS 904L Square Bar
- 904L SS Round Bar Weight Chart
- Chemical Composition
- Mechanical Properties
- Stainless Steel 904L Round Bars price list
- We supply of variety SS 904L Round Bars
- Application Of SS 904L Round Bars
Stainless Steel 904L Bright Bar, UNS N08904 Round Bar, Stainless Steel 904L Hollow Bar, SS 904L Rectangular Bar, 1.4539 Round Bars, 904L SS Hex Bar, 904L Stainless Steel Round Bar Suppliers in India.
Meanwhile, warmth remedy conforms to that for set up austenitic steel. In excessive-strain conditions, Stainless Steel WNR 1.4539 Flat Bars may be with the aid of using and big joined with the aid of using TIG welding. Meanwhile, in business buildings, it’s far used to get throughout cooling or heating water to warmth exchangers, variable air volume (VAV) devices, air handlers, or different HVAC equipment. By approach of getting a composition, is an alloy that gives a grouping of the noble steel traits and the passivation belongings that gives proper corrosion resistance. With base corrosion and wear-resistant and temperature alloys, they may be being categorized as tough to slight while machining.
Meanwhile, viable welding strategies include TIG, MIG, resistance welding, and shielded steel arc welding. However, welding consumable ought to be used for MIG and TIG welding. Alloy 904L Square Bars is an alloy with the aid of using approach of getting excessive corrosion resistance, and holds very an awful lot excessive corrosion resistance in competition to non-oxidizing and oxidizing acids. Hot and Cold work cap-potential are pretty much same to the ones of preferred austenitic steels. And solution warmth remedy right here ought to be finished decrease to a few extents, at 930 Deg Celsius to 1030 Deg Celsius with the aid of fast cooling.
Stainless Steel 904L Round Bars Specifications
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
|---|---|
| Standard | ASTM A276 / A479, ASME SA276 / A479 |
| Hex Bar size | 2-100mm A/F |
| Round bar size | Diameter: 3-~800mm |
| Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Square bar size | 4 to 100mm |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Rectangular Bars Section | 3.0 to 12.0mm thickness |
| Threaded Bar Billet Size | 1/2 to 495mm Diameter |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Surface | Hot Rolled Pickled, Bright, Sand Blasting Finished, Cold Drawn, Hairline,Polished |
| Condition | Hardened & tempered, annealed |
| Technique | Cold Drawn, Hot Rolled, Forged Round Bar,Cold Rolled, Rod |
| Processing | Bar cutting to 650mm |
| Form | Rod, Round, Channel Bar, T-Bar, Flat Bar, Precision Ground Bar, Blocks, Square, Rings, Round Rod, Triangle, Hollow, Rectangle, Threaded, Hex (A/F), Profiles, Half Round Bar, Ingot, Billet, I/H Bar, Forging etc. |
Stainless Steel 904L Round Bars Equivalent Grades
| STANDARD | UNS | WNR. | JIS | BS | KS | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| SS 904L | N08904 | 1.4539 | SUS 904L | 904S13 | STS 317J5L | Z2 NCDU 25-20 | X1NiCrMoCu25-20-5 |
Stainless Steel 904L Round Bars Quality and Test reports
- Third Party Inspection
- EN 10204/3.1B
- 100% Radiography Test
- Raw Materials Certificate
- Mill test
SS 904L Round Bars Surface Finish
| CD | Cold drawn | P | Polished |
| BD | Bright drawn | SRE | Slit rolled edge |
| CG | Centreless ground | HF | Hot finished |
| CF | Cold finished | HRAP | Hot rolled annealed and pickled |
| P&T | Peeled and turned | RT | Rough turned/peeled |
| ST | Smooth turned | PR | Peeled and reeled |
We Supplied a Comprehensive Range Of 904L Stainless Steel Round Bars
Related Types Of Stainless Steel 904L Round Bars
SS 904L Square Bar
SS 904L Hex Bar
SS 904L Flat Bar
SS 904L Rectangular Bar
SS 904L Bright Bar
SS 904L Forged Bar
SS 904L Hollow Bar
SS 904L Threaded Bar
Dimensions Of Hot Rolled Stainless Steel 904L Round Bar
| Diameter or Width (mm) |
Weight per meter | Sectional Area | Perimeter | |||
|---|---|---|---|---|---|---|
| Square (kg) |
Round (kg) |
Square (cm²) |
Round (cm²) |
Square (cm) |
Round (cm) |
|
| 5.0 | 0.20 | 0.15 | 0.25 | 0.20 | 2.0 | 1.57 |
| 5.5 | 0.24 | 0.19 | 0.30 | 0.24 | 2.2 | 1.78 |
| 6.0 | 0.28 | 0.22 | 0.36 | 0.28 | 2.4 | 1.88 |
| 7.0 | 0.38 | 0.30 | 0.49 | 0.38 | 2.8 | 2.20 |
| 8.0 | 0.50 | 0.39 | 0.64 | 0.50 | 3.2 | 2.51 |
| 9.0 | 0.64 | 0.50 | 0.81 | 0.64 | 3.6 | 2.83 |
| 10 | 0.73 | 0.63 | 1.00 | 0.79 | 4.0 | 3.14 |
| 11 | 0.95 | 0.75 | 1.21 | 0.95 | 4.4 | 3.46 |
| 12 | 1.13 | 0.89 | 1.44 | 1.13 | 4.8 | 3.77 |
| 14 | 1.54 | 1.21 | 1.96 | 1.54 | 5.6 | 4.40 |
| 16 | 2.01 | 1.58 | 2.56 | 2.01 | 6.4 | 5.03 |
| 18 | 2.54 | 2.00 | 3.24 | 2.54 | 7.2 | 5.65 |
| 20 | 3.14 | 2.47 | 4.00 | 3.14 | 8.0 | 6.28 |
| 22 | 3.80 | 2.98 | 4.84 | 3.80 | 8.8 | 6.91 |
| 25 | 4.91 | 3.85 | 6.25 | 4.91 | 10.0 | 7.85 |
| 28 | 6.15 | 4.83 | 7.84 | 6.16 | 11.2 | 8.80 |
| 32 | 8.04 | 6.31 | 10.24 | 8.04 | 12.8 | 10.05 |
| 36 | 10.17 | 7.99 | 12.96 | 10.18 | 14.4 | 11.31 |
| 40 | 12.56 | 9.86 | 16.00 | 12.57 | 16.0 | 12.57 |
| 45 | 15.90 | 12.49 | 20.25 | 15.90 | 18.0 | 14.14 |
| 50 | 19.62 | 15.41 | 25.00 | 19.64 | 20.0 | 15.71 |
| 56 | 24.62 | 19.34 | 31.36 | 24.63 | 22.4 | 17.59 |
| 63 | 31.16 | 24.47 | 36.69 | 31.17 | 25.2 | 19.79 |
| 71 | 39.57 | 31.08 | 50.41 | 39.59 | 28.4 | 22.31 |
| 80 | 50.24 | 39.46 | 64.00 | 50.27 | 32.0 | 25.13 |
Stainless Steel 904L Round Bar Size Chart
| Metric | US Bar | ASTM/ Canadian | Japanese | ||||
|---|---|---|---|---|---|---|---|
| Bar Size | Diam. (mm) | Bar Size | Diam. (Inch) | Bar Size | Diam. (mm2) | Bar Size | Diam. (mm) |
| 5 | 5 | #2 | 0.250 | 10M | 100 | 6 | 6 |
| 5.5 | 5.5 | #3 | 0.375 | 15M | 200 | 10 | 10 |
| 6 | 6 | #4 | 0.500 | 20M | 300 | 13 | 13 |
| 7 | 7 | #5 | 0.625 | 25M | 500 | 16 | 16 |
| 8 | 8 | #6 | 0.750 | 30M | 700 | 19 | 19 |
| 9 | 9 | #7 | 0.875 | 35M | 1000 | 22 | 22 |
| 10 | 10 | #8 | 1.000 | 45M | 1500 | 25 | 25 |
| 11 | 11 | #9 | 1.125 | 55M | 2500 | 29 | 29 |
| 12 | 12 | #10 | 1.250 | 32 | 32 | ||
| 14 | 14 | #11 | 1.375 | 35 | 35 | ||
| 16 | 16 | #12 | 1.500 | 38 | 38 | ||
| 18 | 18 | #13 | 1.625 | 41 | 41 | ||
| 20 | 20 | #14 | 1.750 | 44 | 44 | ||
| 22 | 22 | #15 | 1.875 | 48 | 48 | ||
| 25 | 25 | #16 | 2.000 | 51 | 51 | ||
| 28 | 28 | #18 | 2.250 | 57 | 57 | ||
| 32 | 32 | ||||||
| 36 | 36 | ||||||
| 40 | 40 | ||||||
| 44 | 44 | ||||||
| 50 | 50 | ||||||
Standard Sizes ASTM A276 Stainless Steel 904L Hex Bar
| Size in Inches | Wt per Ft | Wt per 12′ |
|---|---|---|
| 3/16″ | 0.104 | 1.248 |
| 1/4″ | 0.180 | 2.160 |
| 5/16″ | 0.290 | 3.480 |
| 3/8″ | 0.420 | 4.920 |
| 7/16″ | 0.560 | 6.72 |
| 1/2″ | 0.740 | 8.880 |
| 9/16″ | 0.930 | 11.16 |
| 5/8″ | 1.150 | 13.80 |
| 11/16″ | 1.390 | 16.68 |
| 3/4″ | 1.660 | 19.92 |
| 13/16″ | 1.950 | 23.40 |
| 7/8″ | 2.300 | 27.60 |
| 15/16″ | 2.600 | 31.20 |
| 1″ | 2.90 | 34.80 |
| 1-1/16″ | 3.30 | 39.60 |
| 1-1/8″ | 3.700 | 44.40 |
| 1-1/4″ | 4.600 | 55.20 |
| 1-5/16″ | 5.100 | 61.20 |
| 1-3/8″ | 5.600 | 67.20 |
| 1-7/16″ | 6.100 | 73.20 |
| 1-1/2″ | 6.600 | 79.20 |
| 1-5/8″ | 7.800 | 93.60 |
| 1-3/4″ | 9.030 | 108.36 |
| 1-7/8″ | 10.400 | 124.80 |
| 2″ | 11.80 | 141.60 |
| 2-1/4″ | 14.920 | 179.04 |
| 2-3/8″ | 16.920 | 203.04 |
| 2-1/2″ | 18.42 | 221.04 |
| 3″ | 26.53 | 318.36 |
Stainless Steel 904L Flat Bar Size
| Flat Bar Sizes in mm | Flat Bar Size (inch) | Flat Bar Thickness (mm) | Flat Bar Thickness (in Inches) |
|---|---|---|---|
| 22 | 7/8 | 17 & 18 | 2/3 – 5/7 |
| 25 | 1 | 5 to 20 | 3/16 – 4/5 |
| 30 | 1-3/16 | 5 to 20 | 3/16 – 4/5 |
| 32 | 1-1/4 | 6 to 20 | 1/4 – 4/5 |
| 35 | 1-3/8 | 5 to 20 | 3/16 – 3/16 |
| 40 | 1-4/7 | 5 to 25 | 3/16 – 1 |
| 45 | 1-7/9 | 5 to 25 | 3/16 – 1 |
| 47 | 1-6/7 | 17,25 & 32 | 2/3, 1 & 1-1/4 |
| 50 | 2 | 5 to 32 | 3/16 – 1-1/4 |
| 55 | 2-1/16 | 5 to 25 | 3/16 – 1 |
| 57 | 2-1/4 | 32 | 1-1/4 |
| 60 | 2-3/8 | 5 to 35 | 3/16 – 1-3/8 |
| 63 | 2-1/2 | 10 to 30 | 3/8 – 1-3/16 |
| 65 | 2-5/9 | 10 to 30 & 35 | 3/8 – 1-3/16, & 1-3/8 |
| 70 | 2-3/4 | 6 to 25 & 40 | 1/4 – 1, & 1-4/7 |
| 75 | 3 | 8 to 25 | 5/16 – 1 |
| 80 | 3-1/8 | 8 to 20 | 5/16 – 4/5 |
| 90 | 3-1/2 | 8 to 20 | 5/16- 4/5 |
| 100 | 4 | 8, 10, 12 | 5/16, 3/8, 1/2 |
Size chart of SS 904L Square Bar
| Square bar Size | KG’s per Metre | Standard Length (metres) | Colour Code |
|---|---|---|---|
| 10 x 10 | 0.81 | 6.0 | Yellow |
| 12 x 12 | 1.16 | 6.0 | Pink |
| 16 x 16 | 2.06 | 6.0 | Grey |
| 20 x 20 | 3.22 | 6.0 | Green |
| 25 x 25 | 5.03 | 6.0 | Purple |
| 32 x 32 | 8.24 | 6.0 | Orange |
| 40 x 40 | 12.8 | 6.0 | Yellow |
| 50 x 50 | 20.12 | 6.0 | Green |
904L SS Round Bar Weight Chart
| Diameter | Weight Chart | Dia | Weight Chart |
|---|---|---|---|
| (mm) | per metre (kg) | (in) | per metre (kg) |
| 3mm | 0.06 | 1/8″ | 0.06 |
| 4mm | 0.10 | 3/16″ | 0.14 |
| 5mm | 0.16 | 1/4″ | 0.25 |
| 6mm | 0.22 | 5/16″ | 0.39 |
| 7mm | 0.30 | 3/8″ | 0.56 |
| 8mm | 0.40 | 7/16″ | 0.77 |
| 10mm | 0.62 | 1/2″ | 1.00 |
| 12mm | 0.89 | 9/16″ | 1.22 |
| 14mm | 1.22 | 5/8″ | 1.56 |
| 15mm | 1.40 | 11/16″ | 1.89 |
| 16mm | 1.59 | 3/4″ | 2.25 |
| 18mm | 2.01 | 7/8″ | 3.07 |
| 20mm | 2.48 | 1″ | 4.03 |
| 22mm | 3.00 | ||
| 24mm | 3.57 | ||
| 25mm | 3.88 |
We Keep Bulk Stock Of 904L Stainless Steel Round Bars At Our Stockyard, Contact Us For Free Sample & Stock List.
Chemical Composition of 904L Stainless Steel Round Bar
| C | Cr | Cu | Mn | Mo | Ni | P | S |
|---|---|---|---|---|---|---|---|
| 0.02 | 19.0-23.0 | 2.0 | 4.0-5.0 | 23.0-28.0 | 0.045 | 0.035 | 1.0 |
Mechanical Properties of 904L Stainless Steel Round Bar
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
|---|---|---|---|---|---|
| Rockwell B (HR B) | Brinell (HB) | ||||
| 904L | 490 | 220 | 36 | 70-90 typical | 150 |
For Stainless Steel 904L Round Bars price list
Request the latest Stainless Steel 904L Round Bars List. Please click on the request a quote button or click here to request the updated price list and ready stock information along with your requirement. Aashish Metal & Alloys maintains a stock of all standard items and can export them at best price for 904L Stainless Steel Round Bars .
We supply of variety SS 904L Round Bars
Aashish Metal & Alloys is a Highly Acclaimed Manufacturer & suppliers of Stainless Steel 904L Round Bars offering all varieties in all types of 904L Stainless Steel in all sizes, with more then 52 countries worldwide.
| Stainless Steel 904L Round Bars | Stainless Steel 904L Wire Mesh |
| Stainless Steel 904L Forged Round Rods | Stainless Steel 904L Cold Drawn Bars |
| Stainless UNS N08904 Hex Rods | Stainless Steel 904L Hot Rolled Round Bar |
| SS 904L Cold Drawn Bars Suppliers | SS 904L Polish Bars & Rods |
| SS 904L Wire Coil Dealer | SS 904L Bright Rods Exporter |
| SS 904L Rectangle Bar Stockholder | Steel 904L Wire Coil Distributors |
| Stainless Steel Wires Suppliers | 904L Spring Steel Bars Manufacturer |
| Stainless Steel DIN 1.4539 Hexagon Bars | Stainless Steel DIN 1.4539 Wire Bobbin |
| Stainless Steel 904L Threaded Rods | SS UNS N08904 Bright Bars |
| ASTM A276 SS 904L Filler Wires | SS 904L Black Bars Stockist |
| ASTM A276 Stainless Steel Bars & Rods | ASTM A479 Stainless Steel Bars & Rods |
Application Of SS 904L Round Bars
